The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home/offices. They are easy to use, reliable, and rugged with metal enclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, etc. With these Plug-and-Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required. Available with 5 ports to 48 ports, these switches also support energy saving technologies to help you save power and money.

10G support	No
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Auto MDI/MDI-X	Y
Auto-negotiation	Y
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Certification	CB, CE LVD, UL
Depth	204 mm
Electromagnetic compatibility	CE, FCC 15 A, IC A, RCM, VCCI, KC
Full duplex	Y
Height	43 mm
Housing material	Metal
Input current	8 A
Jumbo frames support	Y
Latency (1 Gbps)	4 μs
LED indicators	Activity,Link,PoE,Power,Speed
MAC address table	8000 entries
Mean time between failures (MTBF)	667762 h
Networking standards	IEEE 802.1p,IEEE 802.3at
Number of fans	2 fan(s)
Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	0 - 45 °C
Packet buffer memory	0.192 MB
Power consumption (max)	400 W
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	24
Quality of Service (QoS) support	Y
Rack mounting	Yes
Storage relative humidity (H-H)	10 - 95 %
Storage temperature (T-T)	-20 - 70 °C
Switch type	Unmanaged
Switching capacity	48 Gbit/s
Total Power over Ethernet (PoE) budget	380 W
Weight	3300 g
Width	440 mm
